Exhaust System

Exhaust System is the piping connection done to turbo side of diesel generator to guide the smoke flow away through pipe outlet, erected in a concerned location. Works involved in Exhaust System are erection & fabrication of exhaust pipe and its related supports (structure/chimney if needed), and also fabrication of dust cleaner, pollution checking point, mesh/rain cap/weather cap to exhaust pipe.

If the provision for MS exhaust pipe is provided within the building (that is shaft or along building wall), then MS exhaust pipe can be directly erected with help of supports (MS channels, MS angles, MS plates and anchor fasteners etc), if the provision is provided outside the building than a self supported structure or chimney should be fabricated (using MS angles, MS channels, MS plates) and installed to the foundation bolts grouted in a strong concrete pedestal.
